Morimoto Switched Power Harness, 2 or 4Banger Bar, 6-8 Pods, BAF130H

Fitment:

Specs:

• Relays: Custom 2x 60A M-Spec (Hard-Potted)
• Switches: 2x Normally-Off M-Spec w/ Amber backlight
• Outputs: 8x or 12x Deutsch DT 2-Pin Female
• Main Input: 12V+/- Battery Ring Terminals (8.5mm ID / 15mm OD)
• Wiring: 10AWG-20AWG Copper Stranded
• Insulation: Black Tech Flex Braided Mesh
• Harness: 1x Morimoto BangerBar Multi-Pod Power Harness
• Switch Subharness 1: 2x M-Spec Push Button Switches
• Switch Subharness 2: Upfitter Switch Inputs (35cm 20AWG)
• Output Extension: 1x 2m/78.7in Extension
• Output Caps: 2x (for un-used outputs)

Installation Guide

For detailed instructions on installation, Click Below
